Metal Lathes for Precision Turning Applications

Discover CNC, mini, and benchtop metal lathes designed for precision turning, prototyping, repair work, and small-part machining across workshops, training environments, and light manufacturing applications.

7 X 14 Mini Metal Lathe
The 7x14 Mini Metal Lathe is a compact, entry-level metal turning machine ideal for hobbyists, beginner machinists, and ecommerce resellers who need real metal-cutting capability in a small,
8 X 16 Mini Metal Lathe
The 8x16 Mini Metal Lathe offers more swing and turning length than the 7x14 model, making it the preferred option for buyers who work with slightly larger parts or need more cutting power. With
9 X 30 Benchtop Metal Lathe
The 9x30 Benchtop Metal Lathe is built for users who have outgrown shorter mini and compact benchtop models. With 800mm between centers, 220mm swing, 1000W motor, and 100mm bed width, it handles
3-Axis CNC Metal Lathe (X15 Series)
The X15 Series CNC Metal Lathe is engineered for workshops and small manufacturers that need the precision and repeatability of multi-axis CNC machining without the footprint or cost of a full
210 X 1000 Benchtop Metal Lathe
The 210x1000 Benchtop Metal Lathe is the longest-bed option in the YS benchtop metal lathe series — purpose-built for users who frequently work with extended workpieces. With 1000mm between centers,
220 X 750 Benchtop Metal Lathe
The 220x750 Benchtop Metal Lathe is a 2024-updated model offering strong workpiece load capacity (200kg), MT5 spindle, and extended 750mm turning length. It is positioned for B2B buyers who want a
220 X 600 Benchtop Metal Lathe
The 220x600 Benchtop Metal Lathe is a premium-specification benchtop machine featuring a 750W brushless DC motor for smoother, more consistent cutting performance. With 220mm swing, 570mm between
9 X 27 Benchtop Metal Lathe
The 9x27 Benchtop Metal Lathe is a practical, well-balanced entry into the benchtop category — designed for resellers, small workshops, and beginner-to-intermediate users who want reliable everyday
9 X 23 Benchtop Metal Lathe
The 9x23 Benchtop Metal Lathe is a versatile, capability-focused machine for users who need threading flexibility, high RPM finishing, and automatic feed in one benchtop package. It supports 8 metric

Product Overview

Our industrial metal lathes are engineered for precision turning, facing, and threading of ferrous and non-ferrous components. Built with high-grade Meehanite cast iron beds and precision-ground guide ways, these machines deliver rigid performance for high-load machining environments. Available in conventional engine configurations and advanced CNC setups, each unit undergoes strict geometric laser alignment and continuous load testing prior to factory dispatch.

Machine Types & Configurations

Conventional Engine Lathes:

Manual and semi-automated operation suited for tool rooms, maintenance shops, and low-to-medium batch production. Features quick-change gearboxes supporting both metric and imperial thread cutting.

CNC Flat Bed Lathes:

Equipped with industrial-grade CNC controllers for repeatable precision, automated multi-tool indexing, and complex contour turning.

Heavy-Duty Large Bore Lathes:

Designed for oilfield pipes, rollers, and long shaft processing, featuring enlarged spindle bores and dual-chuck configurations.

Machine Construction & Components

Bed Structure:

One-piece Meehanite cast iron base, frequency-induction hardened (HRC 50-55) and precision ground to minimize thermal distortion and absorb cutting vibration.

Spindle Assembly:

Supported by high-precision P5 class tapered roller bearings and angular contact ball bearings, ensuring radial runout of less than 0.008 mm.

Drive Train:

Hardened and precision-ground gears (ISO Grade 6) operating in an oil-bath lubrication circuit for smooth power transmission and extended service life.

Apron & Carriage:

Longitudinal and cross feeds driven by precision lead screws with adjustable bronze split nuts to compensate for wear.

Key Features

Rigid tailstock with MT4/MT5 Morse taper quill, equipped with a rapid locking lever and scale indicator.

Enclosed electrical cabinet featuring industrial contactors and internal cooling fans to prevent dust ingress and thermal overload.

Integrated coolant system with a high-flow pump and removable chip tray for efficient chip evacuation during high-speed cutting.

Full-length rear splash guard and interlocked chuck guard complying with safety standards.

Technical Specifications

Model Parameter	Standard Engine Lathe (e.g., CS-6240B)	Heavy-Duty CNC Lathe (e.g., CK-6150)
Max. Swing Over Bed	400 mm (15.7 inch)	500 mm (19.6 inch)
Max. Swing Over Cross Slide	210 mm (8.2 inch)	290 mm (11.4 inch)
Distance Between Centers	1000 mm / 1500 mm (39 inch / 59 inch)	1500 mm / 2000 mm (59 inch / 78 inch)
Spindle Bore	52 mm (2.04 inch)	82 mm (3.22 inch)
Spindle Nose	D1-6 Camlock	D1-8 Camlock
Spindle Speed Range	36-1600 RPM (12 steps)	30-2000 RPM (Inverter/Servo driven)
Main Motor Power	5.5 kW (7.4 HP)	7.5 kW / 11 kW
Tailstock Quill Travel	120 mm	150 mm
Machine Weight	Approx. 1850 kg	Approx. 3200 kg

Materials & Workpiece Compatibility

Ferrous Metals:

Carbon steels (AISI 1045, 4140), alloy steels, stainless steel (304, 316), and grey/ductile cast iron.

Non-Ferrous Metals:

Aluminum alloys (6061, 7075), brass, bronze, and copper.

Workpiece Geometry:

Solid bars, hollow tubes, stepped shafts, flanges, and pre-cast components requiring concentric turning, boring, and external/internal threading.

Applications

Automotive Industry:

Machining drive shafts, axle stubs, brake rotors, and transmission components.

Energy & Oilfield:

Processing drill collars, valve bodies, couplings, and pipeline maintenance fittings.

General Engineering:

Tool and die making, maintenance and repair operations (MRO), and custom job-shop component fabrication.

Manufacturing & Quality Control

Foundry Processing: In-house casting annealing and stress-relief heat treatment cycles to eliminate residual internal stresses before machining.

Machining Precision: Bed ways milled and ground on heavy-duty plano-millers and CNC guideway grinders.

Inspection Protocol:
Laser interferometer calibration for axis positioning and repeatability.

Dynamic balancing of spindle assemblies.

Dial indicator testing for geometric alignment (spindle runout, tailstock parallelism, cross-slide squareness).

Certifications: Standard quality management system compliance and safety certification for international export markets.

Customization & OEM

Voltage and frequency adaptation (e.g., 220V / 440V, 3-phase, 60Hz or 380V, 50Hz).

Specialized chuck options:

3-jaw self-centering, 4-jaw independent, pneumatic, or hydraulic chucks.

Tooling integration:

Quick-change tool posts, 4-position electric turrets, or 8-station hydraulic turrets.

DRO (Digital Readout) installation:

2-axis/3-axis systems pre-installed and calibrated.

Frequently Asked Questions

Q: What is the standard electrical supply required, and can the machine be configured for regional power?

A: The machines operate on standard industrial 3-phase power. Units can be built with transformers or dual-voltage motors configured for specific local voltage and frequency requirements, accompanied by compliant electrical components upon request.

Q: How do you ensure the long-term accuracy and straightness of the lathe bed?

A: The bed is cast from high-density Meehanite iron, subjected to natural aging and thermal stress-relief annealing. The guide ways are induction-hardened to HRC 50-55 and precision ground. This process ensures wear resistance and maintains geometric tolerances over years of heavy cutting.

Q: Are the threading gearboxes capable of cutting both metric and inch threads without changing gears?

A: Standard manual engine lathes feature a comprehensive gearbox that allows operators to switch between metric, inch, module, and diametral pitch threads simply by adjusting external selector levers, minimizing setup time.

Q: What inspection documentation is provided with each machine delivery?

A: Every metal lathe ships with an individual factory inspection test report. This document records specific measurements including spindle radial runout, parallelism of the tailstock quill to the spindle axis, and laser-verified lead screw accuracy.

Q: How are replacement parts and wearing components managed after purchase?

A: We maintain a complete inventory of standard wearing parts, including lead screws, bronze split nuts, drive belts, bearings, and pump assemblies. Common components are dispatched from stock to minimize customer downtime.

Q: What is the typical lead time for standard models versus customized CNC configurations?

A: Standard conventional engine lathes in common bed lengths (1000mm / 1500mm) typically have a production and crating lead time of 30 to 45 days. Customized CNC configurations or specialized voltage requirements generally require 60 to 75 days, including extended testing and burn-in cycles.
